Transfer Carts

Our company produces various standard, non-standard and unconventional types of transfer flat vehicles and material handling equipment ranging from 1 to 500 tons. The products comply with the JB/T6127-2010 machinery industry standard and feature novel, compact, practical and durable structures, beautiful appearance, accurate positioning, simple and convenient operation, smooth turning and driving, strong climbing ability, long driving distance, low noise and easy operation. Maintenance, wired or wireless operations and other operations can be performed.

Remark: Flagcrane can customize all kinds of material handling equipment such as rail transfer cart, trackless transfer cart, AGV, trailer, etc. You can click to CONTACT US!

Warranty: 2 Years

Capacity: 1- 500 tons

Certificate: CE SGS ISO, SASO and others

Advantage: Peculiar set-up makes the transfer cart save cost and operate more conveniently

Send Your Inquiry Now Mail Us:info@cranespreader.com

Why Choose Flagcrane As Your Transfer Carts?

Flagcrane is a professional group company integrating crane design, manufacturing, sales, installation, after-sales and maintenance. which is located in Changyuan Crane Industrial Park, Henan Province, with a registered capital of 560 million yuan, covering an area of more than 850,000 square meters and a modern heavy steel production workshop of more than 400,000 square meters. There are more than 1,600 employees, including more than 200 middle and senior professional technicians and management personnel.

Flagcrane's equipment has passed ISO, CE, SGS, SABER and domestic and foreign other professional certification.

The spreaders manufactured by Flagcrane meet the standard and non-standard design and manufacture, and provide suitable solutions for different customers.

Send Your Inquiry Now

Why choose Flagcrane As Your Transfer Cart?

Our transfer carts allow movement charges at ground level in all types of industries and applications. The transfer carts are rugged and modular construction, available in a wide range of products also can be adapted to suit your need. They are equipped with all the safety devices needed for ground-level machinery movement. Transfer carts are an important complement to cranes lifting heavy loads at ground level and the ideal solution for cargo transfer between ships.

Customized capacity from 1 ton to 500 tons
Battery powered (Optional power source)
Robust Sturdy Frame
Omnidirectional: various steering on client request (normal, 90° , diagonal, 360° and many others)
Maintenance Free Battery and Intelligent Charger
Low battery alarm device. lt will alarm, when the battery power is too low.
Any kind of wheels (polyurethane,vulkollan, solid, super elastic or pneumatic))
Anti-explosion, anti-high temperature,anti-water, anti-dust, etc
Customized system(lifting, weighing, titling, climbing, ferry,plc, etc.)
Optional Control System (Operation handle / Remote Controller / Cabin)
Safety System(LED flashing lights, Sound acoustic devices,E-stop, Dead man stop, Buffer, etc.)
Speed up to 10 Km/h
Well known components brand.

Flagcrane engineeing team will always provide the opftimal uiding nethod based on your sie layout and requests to offer you the best product with the compettive pric.

Send Your Inquiry Now

Application of Flagcrane Transfer Carts

Transfer cart is widely used in material transportation in workshops and working areas, and is widely used in metallurgy, coal, mining, electromechanical, heavy industry, light industry, automobiles, shipbuilding, railways, docks and other industries.

Flagcrane can adjust the operation parameters, components and options of the transfer carts so you will be able to:

Loading or unloading materials from a truck
Moving materials around a facility more efficiently than a tow motor or manpower can
Flipping or pulling dies in and out of stamping machines at a manufacturing facility
Feeding raw material into a machine at a manufacturing facility
Moving pieces or parts down an assembly line in a controlled fashion
Moving containers around a shipyard or railyard
Moving goods or equipment in special areas such as mines, oil fields, power plants, and food workshops

Send Your Inquiry Now

Hoists Options


1. AGV Transfer Cart Factory	2. Automated Transfer Cart	3. Steerable Transfer Cart

4. Trackless Transfer Trolley	5. Electric Transfer Cart	6. Tire Type Trackless Transfer Carts

7. Coil Transfer Cart	8. Battery Power Transfer Cart	9. Ladle Transfer Cart



10. Industrial Transfer Cart	11. Cable Reel Powered Transfer Cart on Rails	12.RGV Rail Transfer Cart



13.Lifting Transfer Cart	14. Self-Propelled Diesel Powered Transfer Cart	15. Hand Operated Electric Transfer Cart

Video
Certification
Parameters
Production Process

Technical Data：

Rated Capacity (t)	5	10	15	20	30	40	50	Customized
Test Capacity (t)	7.5	15	22.5	30	45	60	75	Customized according to Capacity
Frame Structure	Steel Plate Welded Beam Structure
Steel Plate Thickness (mm)	8	10	12	14	14	16	16	Customized according to customer requirements
Weight (t)	4.3	5.3	6.6	7.9	8.8	10	10.5	Customized
wheel pressing (t)	2.8	4.6	4.3	5.6	7.7	10	12	14
Ground Requirements	Concrete floor/steel plate floor
Dimensions (mm)	3000*2000	3600*2000	4000*2200	4500*2200	5000*2200	5500*2300	6000*2300	Customized
Height (mm)	450	530	600	600	650	700	700	Customized
Ground Clearance (mm)	50	50	50	50	50	50	50	Customized
Rail Center Distance (mm)	1500	1500	1700	1700	1700	1800	1800	Customized according to body size
wheelbase (mm)	2500	3100	3400	3900	4300	4800	5200	Customized according to body size
Turning Radius (mm)	2501	3101	3401	3901	4301	4801	5201	Customized according to body size
Turning Method	Continuous Walking and Turning
Electric Turning Control	Electrical Button Control

Please Note: Above specification just for your reference,our transfer carts can be Customized Design based on Your Requirements.

A Standard Transfer Cart Will Be Produced In 20 Days.


1.Customized Design	2.Raw materials	3.Cutting production

4.Heat treatment and finishing of machined workpieces	5.Assembly	6.Inspection

7.Painting	8.Delivery	9.Installation & Acceptance
